Fiber alignment

Core/cladding alignment / Manual alignment

Splicing time

5s

Heating time

15s

Heating mode

Automatic heating (Preheating)

Focus mode

Six motors Auto focus

Applicable Fibers

SM(G.652&G.657),MM(G.651),DS(G.657),NZDS(G.655)

Splice Loss

0.025dB(SM)  0.01dB(MM)  0.04dB(DS/NZDS)

Control technology

Real-time control and calibration of fusion ARC

Return Loss

Better than 60dB

Fiber diameter

Cladding Diameter: 80-150um   Coating Diameter:100-1000um

Fiber Cleave Length

Coating less than 250um: 8-16mm  Coating less than 250-1000um:16mm

Built-in lighting

Easy for night operation

Tension Test

Standard 2N

Fiber holders

3 in 1 fiber holder, SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable

Magnification

300 for X or Y view, 150 for X or Y view

Screen

5 inch TFT color display

Splicing Mode

Normal / high precision splicing

Splicing record storage

Synchronize to the phone, the server to cloud storage unlimited

Built-in battery

7800 mA high-capacity lithium battery, charging time ≤3.5 hours,

continuous splicing and heating about 240 times

Power supply

Input AC 100-240V 50/60HZ, output DC 13.5V/4A, the current power mode can be identified,real-time detection of battery power

Operating Conditions

Temperature: -15~+50°C, humidity: <95%

Working altitude: 0~5000m, resist max, wind speed: ≤ 15m/s

Shrinkable tube

60mm,40mm
